ERGONOMICS
• two completely independent treatment channels
• operation mode: program / manual
• preset treatment program and sequence base
• statistics
• encyclopedia with treatment methodology description
• treatment programs chosen by name or medical field
• concise list of favorite programs and sequences
• buzzer volume setting
• possibility of edition the names of user-defined programs and sequences
• self-test – systematic control of the unit
• 7” color touchscreen
• real time clock
• model PHG101A – battery unit
• operation in CC (stabilized output current) and CV (stabilized output voltage) modes
• electrodes test
• generation of unidirectional (unipolar) currents in interrupted mode
• complete galvanic isolation between channels in each mode
CURRENTS
– interferential (dynamic, isoplanar, one-channel (AMF))
– TENS (symmetric, asymmetric, alternating, Burst)
– TENS to spastic paralysis therapy
– Kotz’ / Russian stimulation
– tonolysis
– diadynamic (MF, DF, CP, CP-ISO, LP)
– pulse – rectangular, triangular
– Trabert pulse, Leduc’ pulse
– unipolar sine surge
– galvanic
– microcurrentsELECTRODIAGNOSTICS
• electrodiagnostics with graphic presentation of I/t curve
• automatic calculation of rheobase, chronaxie as well as threshold, coefficient and quotient
of accommodation
MANUAL MODE
complete control over parameters for advanced users
TREATMENT PROGRAMS
• 69 preset treatment programs
• 50 user-defined programs
• 69 favorite programs
TREATMENT SEQUENCES
• 38 preset treatment sequences
• 10 user-defined sequences
• controller – max constant current in patient’s circuit (CC mode)
– galvanic 40 mA
– diadynamic, pulse 60 mA
– interferential, Kotz, unipolar sine surge 100 mA
– TENS 140 mA
– tonololysis 100 mA
– microcurrents 1000 μA
• max voltage in patient’s circuit (CV mode) 140 V
• mains supply 230 V, 50/60 Hz, max 75W, 90VA
• dimensions 34 x 28 x 11‐16 cm
• weight 6 kg
STANDARD ACCESSORIES
• mains cable
• patient’s cable (2 pcs)
• electrotherapy electrodes 6 x 6 cm (4 pcs); 7,5 x 9 cm (2 pcs)
• viscose electrode covers 6 x 6 cm (8 pcs); 7,5 x 9 cm (4 pcs)
• velcro fixing belts 40 x 10 cm (2 pcs); 100 x 10 cm (2 pcs)
• spare fuses WTA-T1 A/250 V (2 pcs)
• touchscreen stylus pen (1 pcs)
• touchscreen cleaning cloth (1 pcs)
OPTIONAL ACCESSORIES
• disposable self-adhesive electrodes 3 x 4 cm; 5,5 x 5,5 cm; 5,5 x 12,5 cm
• point electrodes 6 mm, 10 mm, 15 mm, 20 mm
• crocodile clip
• sand-filled bag 21 x 14 cm, 21 x 28 cm
• combination therapy cable
• patient’s stop switch
• bag for the unit and accessories
• Elf X trolley
• battery
