Tuttnauer’s ML laboratory line of semi-automatic, electro-mechanically controlled, vertical steam sterilizers provide safe, economical and effective sterilization.
The semi-automatic laboratory autoclave series is an affordable sterilizer for laboratories that do not want to compromise on quality, safety and reliability and need to sterilize loads with low sensitivity. The semi-automatic series is available in floor standing, vertical or benchtop models and in chamber sizes ranging from 23 to 160 liters. Process control is preformed by a pressure switch.The semi-automatic control system includes a timer that can be set from 1 to 99 minutes. The ML models have a semi-automatic control panel.
STERILIZATION APPLICATIONS
Liquids such as nutrient media and buffer solutions
Solid items such as pipettes, tubes and filters
Glassware and plastic articles
SAFETY FEATURES
The autoclave lids are designed with a number of independent mechanical and digital safety features.
A safety device prevents the operator from opening the door when the chamber is pressurized
A cycle cannot start if the door is open or not properly locked
The door cannot unlock until chamber pressure reaches room pressure
Safety Valves: The chamber is equipped with safety valves – if the pressure exceeds the allowed limit the safety valves will discharge
QUALITY FEATURES
The chamber is constructed of long lasting 316Ti grade stainless steel with superior corrosion resistance
The autoclave is designed for easy servicing allowing maintenance access to all components
Drain Protection: The exhaust drain is mixed with cold tap water that cools the exhaust’s temperature before reaching the drain.
STERILIZER DIRECTIVES AND STANDARDS COMPLIANCE
Tuttnauer’s high quality laboratory autoclaves comply with the strictest international directives and standards.
Pressure Equipment: PED 97/23 EEC, EN 10028-7, ASME Code Sec VIII
Safety: IEC/UL/EN61010-1, IEC 61010-2-040, EN 61326
Sterilization: DIN 58951 Series, ISO 17665-1:2006
Quality System: ISO 9001:2000, ISO 13485:2003
